9GV0948H101

Name: Sanyo Denki 9GV0948H101
Brand: Sanyo Denki
SKU: 978-9GV0948H101
Price: 56.89 SGD
Availability: OutOfStock

Images are for reference only
See Product Specifications

Mouser No:

978-9GV0948H101

Mfr. No:

9GV0948H101

Mfr.:

Sanyo Denki
Sanyo Denki

Description:

DC Fans DC Axial Fan, 92x92x38mm, 48VDC, Guide Vane, Tachometer

Datasheet:

9GV0948H101 Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about Sanyo Denki 9GV0948H101

Availability

Stock:: Non-Stocked

An unexpected error occurred. Please try again later.
Factory Lead Time:: 16 Weeks Estimated factory production time.

Enter Quantity:

Minimum: 28 Multiples: 28

Unit Price:

$-.--

Ext. Price:

$-.--

Est. Tariff:

This Product Ships FREE

Pricing (SGD)

Qty.	Unit Price	Ext. Price
	$56.89	$1,592.92
	$55.39	$3,101.84
	$55.38	$6,202.56
	$55.36	$13,950.72

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Sanyo Denki
Product Category:	DC Fans
RoHS:
Type:	Axial
Height:	92 mm
Depth:	38 mm
Width:	92 mm
Operating Supply Voltage:	48 VDC
Airflow:	178 CFM (5 m3/min)
Speed:	8500 RPM
Bearing Type:	Ball
Noise:	64 dBA
Power Rating:	39.4 W
Features:	Tachometer
Housing Material:	Plastic
Termination Style:	Wire Leads - 3
Series:	9GV Type
Brand:	Sanyo Denki
Current Type:	DC
Packaging:	Bulk
Pressure Type:	39 mmAq
Product Type:	DC Fans
Factory Pack Quantity:	28
Subcategory:	Fans, Blowers & Accessories
Tradename:	San Ace 92
Part # Aliases:	3784320 05W9515
Unit Weight:	250 g

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0


Only BASE MODELS appear on datasheet. This part number represents a special option with PULSE SENSOR. Please see TEST/QUALITY DATA

docs on mouser.com for full table of special numbers and the associated base number that appears on the main datasheet.

Please contact a Mouser Technical Sales Representative for further information.

5-0719-19

Filter Document:

Technical Resources

Test/Quality Data

CNHTS:: 8414599050
CAHTS:: 8414590091
USHTS:: 8414596590
TARIC:: 8414592590
ECCN:: EAR99

9GV Type Guide Vane Fans

Sanyo Denki 9GV-Type Guide Vane Fans utilize Guide Vane technology, which achieves industry-leading performance with high airflow and back pressure while reducing power. These axial or tubeaxial fans are available with a 12V_DC, 24V_DC, or 48V_DC operating supply voltage. The 9GV-type fans feature a 13.1CFM to 1112CFM airflow range, a 3000RPM to 24,000RPM speed range, a 43dBA to 81dBA noise range, and a 2.52W to 600W power rating range. The models with a PWM control function also have a motor protection system that includes a current blocking function and reverse polarity protection.
